CNC Carbide Small hole inner diameter grooving blade 9GR200 For Cutting Off

Technical information :

Slotting and separation are unique turning applications for many machining applications that require special tools. These tools can be regarded as the extension of ordinary turning to some extent.
Slotting and separating operations should consider three different aspects to determine the best method and mold solution:
Features of parting and grooving workpiece:
Analysis of groove size and quality requirements to be processed: processing type, groove depth, groove width, outer radius and quality requirements.
Workpiece material, shape and quantity.
Whether the material has good chip breaking performance
Production batch: single or batch slotting
Whether the workpiece can be clamped safely
Chip removal
Machine parameters.
Stability, power and torque, especially for large components
Cutting fluid and coolant
Whether the long chip material needs high-pressure coolant to break chips
Speed limit
Use all possible support
Timely replacement of worn blades will make the cost of new blades more economical than that of excessively worn blades.
Replace worn or damaged rods.
Don't try to repair the turret.

This type of knife has the following characteristics:
(1) The blade is not welded at high temperature, which avoids the defects such as hardness reduction and crack of the blade caused by welding, and improves the durability of the tool.
(2) As the tool durability is improved, the service time is longer, the tool change time is shortened, and the production efficiency is improved. (3) The cutter bar can be reused, which not only saves steel but also improves the utilization rate of the blade. The blade is recycled by the manufacturer, which improves the economic benefits and reduces the cost of the tool.
(4) After regrinding, the size of the blade will gradually decrease. In order to restore the working position of the blade, the adjustment mechanism of the blade is often set on the turning tool structure to increase the number of regrinding of the blade.
(5) The end of the pressing plate used for pressing the blade can act as a chip breaker.

We are trading company have two factory in Sichuan .China.

A manufacturer with 8 years experiences of producing carbide cutting tools,

including carbide turning,milling,threading,grooving insert,carbide end mill,drill bits,etc.

has an advancedcarbide cutting inserts production line and product testing line .our company is committed to research and development andlocalization of the cutting insert cutting insert new materials ,professional design and production of carbide blade foldermachine , CNC blades ( knives ) , stand -mounted cutter,dedicated blade iso standard and non-standard type products isthe field of carbide cutting inserts emerging enterprises.

Complete specification of carbide milling insert.

Currently we have more than 2000 different products from mainly brand all over the world.

sandvik,iscar,mitsubishi,kyocera,korloy,sumitomo,etc.

We can provide free samples for most products (except for a few special ones, we can communicate with you in detail).You can add me whatsapp to Communicate more.

My company adheres to the business philosophy of ' branding with integrity, branding with quality, and branding with benefits '.It focuses on customer interests and adheres to the implementation of branding strategy to expand market share. We ' professional, professional, expert ' for the purpose of serving you, with you to establish a long-term strategic partnership, continue to provide professional solutions for the cemented carbide industry.
